Noticias

Últimas Noticias
Jornada técnica sobre el estudio de selectividades y protección de arco interno en los cuadros CCMs




Tuvo lugar el pasado miércoles 28 de mayo en el Colegio Oficial de Ingenieros Técnicos Industriales de Valladolid con gran éxito de convocatoria.


La seguridad en las instalaciones eléctricas de baja tensión ha ido cobrando una creciente importancia. Es imprescindible anteponer la seguridad a cualquier otro requisito en una instalación eléctrica y realizar una selección adecuada de las protecciones a instalar durante su fase de diseño, de modo que ante un fallo, éste quede aislado sin interrumpir el suministro eléctrico en el resto de la instalación.


En esta jornada se ofreció a los asistentes información técnica sobre el diseño de la instalación en cuanto a selectividad y filiación, proporcionando una herramienta informática, así como información técnica acerca del arco interno y de los cuadros de centros de control de motor (CCM).
  Terasaki expone en Hannover y MEE



Este año Terasaki participará en dos grandes eventos industriales: Middle East Electricity Exhibition en febrero y la Feria de Hannover en abril.

Del 11 al 13 de febrero 2014 Terasaki Electric estará presente en el Pabellón BEAMA del Dubai World Trade Centre, Stand 2E20.

En abril, del 7 al 11, Terasaki expondrá en Hannover. Nos encontrarán en el Pabellón 12, Stand C82.

Queremos aprovechar ambas ferias para celebrar el 90 aniversario de Terasaki. Por ello, estamos preparando algunas sorpresas para nuestros visitantes. Nuestro equipo estará encantado de darles la bienvenida en ambos eventos. ¡Esperamos verles muy pronto!

Back to top
  Nuevo Software de Diseño

El Software TemCurve de Análisis de Selectividad se ha conformado entorno a la extensa gama de interruptores automáticos Terasaki.

El software también incluye un gran número de dispositivos de protección complementarios tales como fusibles de Alta y Baja según BS88/IEC269, Relés IDMT según Norma BS142/IEC255.  En consecuencia, TemCurve puede ayudarle en la gradación de los dispositivos de protección desde el primario del transformador hasta el punto final de distribución.
Dispone de una excepcional función ‘haga clic y arrastre’ para producir estudios de sobreintensidad y defecto a tierra.

Puede descargarse la nueva versión TemCurve 2.0 Lite aquí.


  Inserción en revista ELECTRA nº 179 junio 2013

Artículo técnico: Interruptores de caja moldeada (Donald Río – Director Técnico) & Anuncio.

a

a



Back to top
  Terasaki expone en MATELEC 2012

TERASAKI participa en el próximo certamen de MATELEC con stand propio.

Si desea visitarnos, puede conseguir un pase profesional siguiendo el link que encontrará a continuación. Debe registrarse utilizando los códigos exclusivos para nuestros clientes.

DESCARGUE AHORA SU PASE DE VISITANTE PROFESIONAL CON ESTE CODIGO

TEXT:   4A01A      NUM:   761987

En el marco de la Feria organizamos unos seminarios pensados para la presentación de nuestras novedades en producto.

Seguro que encontrará una fecha que se adecúe a su visita:

Martes 23 a las 16:30 h
Jueves 25 a las 15:30 h
Viernes 26 a las 12:30 h

Pabellón 4 - BOX 4.3

Duración: 45 minutos.

Plazas limitadas

¡Venga a nuestras charlas y se llevará un estimulante recuerdo!
Back to top

   Entrevista Electra
Back to top
   New Pro-DB Distribution Board and Pro-Panel Panelboards

Terasaki’s new distribution equipment meets the needs of modern commercial and industrial building electrical installations. Complying with UK regulations and standards for building projects*. The range includes Distribution Boards, Panel Boards and Integrated Metering Solutions.

New TP&N Offer

Pro-DB Type B distribution boards are fully type tested with a conditional short circuit rating of 25kA to BS EN 60439. Variations for the 125A TPN board include a choice of: 4, 6, 8, 12, 18 and 24 TP outgoing ways. For applications where the number of MCB ways requires a larger supply current, a 250A rated TPN version is also available in 8, 12, 16, 18 and 24 outgoing ways.

Complementing the Pro-DB distribution board is a completely new range of TD3 MCBS and single module RCBOs, providing the highest levels of safety and performance required for your installation. Assuring our customers that they are buying a component of good quality

Facilitating various industrial and commercial distribution applications, the choice of incomer options include: Switch Disconnectors, MCCBs, RCCBs and Contactor incomers. The TP&N distribution board can easily be converted to a SP&N system by utilising a single phasing kit for both 125A and 250A ratings.

Compact Solution for Energy Metering

Integrated metering can be easily achieved by simply adding a meter next to the incoming device in the 125A & 250A board. This means that simple energy meters (kWh) with pulsed output, digital multifunction meters with pulsed output or digital multifunction meters with Modbus output can be installed inside the board without the need for an extension box.

Split metering of lighting and power loads in the distribution board enables compliance with the building regulations in the UK. Pro-DB TP&N boards can separately monitor lighting and power loads by utilising dual metering kits in horizontal board configurations. Separate metering facility for a 125A board is also available in a vertical board configuration.

With generous wiring space and a unique cable entry system, why not switch over to the Pro-DB distribution range? Contact marketing@terasaki.co.uk for our Pro-DB price list and product brochure.
*BS7671 and Part L2 The Building Regulations 2000 (2006 edition).
Back to top
   Discover NEW Switchgear Solutions from Terasaki at the Hanover Fair 4th-8th April, Stand No: E71 Hall 13

INVITATION


We are delighted to invite you to join us at the Hanover Fair. We will exhibit together with EFEN, our distributor in Germany, in a prime position in the middle of Hall 13.

Our Directors, Managers and Staff will be available to discuss all your business requirements, and to explain our recent innovations, including:



• New TemBreak 2 MCCBs which can save space and money up to 250A, 40kA

     • MCCBs for use is photovoltaic systems at voltages up to 1000V DC

     • New range of MCBs, RCDs and RCBOs

SEE OUR PRODUCTS INSTALLED IN SWITCHBOARDS

TemPower 2 ACBs and TemBreak 2 MCCbs will be installed in simple switchboards on our stand for your inspection. You can also view our products in type-tested systems by our partners at the following stands:

• CUBIC Stand D40, Hall 12
• RITTAL Stand E06, Hall 11
• Wöhner Stand C66, Hall 12
HAPPY HOUR

17:00 to 18:00 will be Happy Hour on our stand. We hope you can join us at that time for a chat, a snack and a drink!

APPOINTMENTS

Contact David Wales NOW to make an appointment for a meeting or to arrange for a ticket for free entry to the Exhibition.
Telephone: +44 141 565 1689

Back to top

   Middle East Electricity Exhibition

Terasaki Electric Europe Ltd participated at the Middle East Electricity Exhibition from the 8th to 10th February 2011, in a joint stand with our partner for UAE, Al Ghandi Trading. Our joint stand was 36sq meters with 15sq meters apportioned to Terasaki.

This exhibition provided an opportunity to promote our new range of products including Space Saving MCCBS up to 250A and TD3 range of Miniature Circuit Breakers. Tom Craig (General Manager) presented two seminars on the Application of Circuit Breakers which were well received.
For further information on these new product ranges, please contact Terasaki.

Back to top

   Terasaki and Mardix Pass Test at One Hundred Thousand Amps

Terasaki and Mardix are delighted to announce the success of their joint switchgear testing program. Engineers at Mardix have designed a new industry-leading, high-capacity distribution switchgear system incorporating Terasaki circuit breakers. Intended for use in buildings with high, concentrated electrical energy demand such as data centres and banks, it has now been proven to withstand short-circuit fault current of up to one hundred thousand amps (100kA).



Peace of Mind from Independent Testing and Certification to IEC 61439

The consequences of switchgear failure when a business depends heavily on the availability of electricity could be disastrous. Terasaki and Mardix had the system independently tested and certified to give users and specifiers peace of mind about the performance of the equipment.

Short-circuit performance at 100kA was tested at the ASTA-approved DAMSTRA laboratory in the Netherlands.

Temperature performance was verified at kA Testing in the UK (also ASTA-certified). This highlighted the superior thermal performance of the switchboard and circuit breakers in that:


• a rating of 6300A for the incoming circuit (a TemPower 2 ACB) was achieved with natural cooling;

     • Outgoing circuits rated from 160A to 3200A (TemBreak 2 MCCBs and TemPower 2 ACBs) achieved a diversity factor of         1 with natural cooling.

Latest Switchgear Standard

The system was designed and tested to the latest standard for low-voltage switchgear assemblies, IEC 61439. ASTA certificates are available and reference the new standard.

Collaboration Offers Choice to Clients

Terasaki and Mardix are independent companies, successful in their separate, but overlapping business areas. Terasaki are the UK’s foremost circuit breaker specialists, supplying components to switchboard builders for a wide range of commercial, industrial and marine projects. Mardix deliver an integrated solution for every aspect of the critical power life cycle through switchgear, power management and service.
The co-operation between Terasaki and Mardix offers choice to clients who like to select the best technical solution for a project without being restricted to using the same brand for systems and circuit breakers due to existing certification. Some examples of the benefits of this “best of breed” approach are:

     • Reduction in space required for switchgear in the building. 100kA short-circuit withstand ratings can achieved in         1400mm wide incoming switchgear compartments. This is possible only due to the unique combination of Air Circuit         Breakers with exceptional ratings (Terasaki) and busbar design (Mardix) and can result in space savings of up to 40%         over conventional designs.

     • Overheating is the single most common cause of failure in switchgear. Full critical power monitoring systems,         incorporating real-time, continuous thermal measurement of circuit breakers is an easily achieved option with this         combination of equipment.


More Details

For more details of the tested solutions from Terasaki and Mardix, contact:

     • Terasaki: Tim Campbell, Marketing Manager. tim.campbell@terasaki.co.uk
       Telephone: 0141 941 1940

     • Mardix: Clare Coxon, PR Agent. clare@tenstories.co.uk
       Telephone: 015395 64242


Back to top

   TERASAKI Circuit Breakers Type-Tested With CUBIC

Two independent and innovative switchgear companies have co-operated to conduct a successful type-testing programme.

Terasaki and CUBIC are independent and innovative companies who have co-operated to offer one of the world’s most compact switchboards certified at up to 100kA - Icw for one second, containing Terasaki circuit breakers from 12A to 6300A.

We have proven the performance of our products together with a test programme, certified by KEMA and ASTA, at fault levels of 65kA, 80kA and 100kA.

This delivers unsurpassed circuit protection with built-in reliability and safety, giving confidence for the future of energy distribution.

Tests conducted:
   • Temperature rise
   • Dielectric properties
   • Short-circuit withstand strength
   • Effectiveness of the protective circuit
   • Creepage and clearance
   • Mechanical operation
   • Degree of protection
   • EMC
   • Resistance of insulation materials
   • Partial test to IEC 61439-1,-2
   • Internal arc fault containment to AS3439-1
Annex ZD and AS3000

Terasaki products included in this testing;

Moulded Case Circuit Breakers (MCCBs) - TemBreak2

One of the most powerful features of the TemBreak2 MCCB is that it is so easy to install and operate - it was designed that way.
TemBreak2 MCCBs are now available with high tech integrated LCD energy monitor which can be connected to an Automatic Monitoring and Targeting system.

The TemPower 2 ACB is extremely reliable in service.
All models in the range have a short-time withstand rating equal to their service breaking capacity. This guarantees total discrimination without further calculation because it allows short-circuit protection to be time-delayed even at the maximum prospective short-circuit current.

Back to top

   New Product Selection Book

We have produced a new combined product selection book, PL0809.The new publication combines product selection tables for Air Circuit Breakers, Moulded Case Circuit Breakers and Distribution products in one comprehensive user-friendly reference document.

The 139 page publication, with full price listings, is split into application-specific areas, with the main index providing a quick reference guide with pictures highlighting the key product areas.

Tim Campbell, Marketing Manager advised that Terasaki’s policy of continuous innovation means that they have made significant developments to all their ranges of electrical and safety protection products:

   • TemBreak 2 MCCBs with integrated power and energy metering now available to order
   • Neutral links designed to match the terminal arrangements of 4P MCCBs – with optional moulded shrouds
   • Optional protection relays with manual reset facility for TemPower 2 ACBs
   • Optional ready-to-close contact for TemPower 2 ACBs
   • TemWay 100: a new single-phase distribution board
   • TemWay 250 LP: a split-metered distribution board for lighting and power

Terasaki’s delivery performance team have been working hard since last autumn to ensure that deliveries are the most reliable in the market place. This approach is strengthened by excellent technical support to ensure their customers receive the best possible performance and service.


Click here to download the product selection book
Back to top

   Save Space with Power Factor Correction Modules
Terasaki supply a complete range of products and systems for low, medium and high voltage power factor correction.

Our new ECCTT small units have been designed to be installed extremely easily in automatic power-factor correction equipment. The units offer a 70% reduction in width compared with our standard PFC modules, allowing for higher packing density and a reduction in the size of compartment. This will assist in minimizing switchboard size, and generally save costs.

We also offer standard modular cassettes for switchboard installation and prefabricated freestanding automatic capacitor banks.

Available types are:

   • ECCTT.40125 25Kvar 400V 50Hz Modular Unit
   • ECCTT.40150 50Kvar 400V 50Hz Modular Unit

Unit Specifications:

   • Cable connection.
   • Frame is galvanized sheet steel.
   • Set of three fuses which are NH00 curve gG with a high breaking capacity.
   • Flameproof connecting cables type N07VK.
   • The capacitors are the “dry” type, manufactured using self-healing metallised       polypropylene film. The capacitors are equipped with an overpressure       disconnecting safety device that at the end of its life or in the event of a failure       due to overvoltage, immediately cuts off the circuit power supply.
   • Minimum of 10mm horizontal and 20mm vertical spacing is required between units.


Small Modular Tray with Cable Connections
(L 150mm x W 250mm x H 400mm)

Quality and reliability of our equipment is guaranteed. Capacitors are designed to meet the requirements of IEC 60831-1/2, IEC 60871-1 and IEC 60871-2. End-users like Pirelli, VATech and Michelin rely on our range for power factor correction.

Back to top
